titanium grade 7 round bar

Product Name:

titanium grade 7 round bar

No. :

Product Description:

Titanium grade 7 round bar

Place of Origin:Shaanxi BaoJi China (Mainland)
Application:Industry,Aerospace
Diameter:≥1.0mm
Length:≤6000mm(normal szie)
Technique: Cold Rolled, hot rolled
Grade:GR7
Product Name;titanium grade 7 round bar
Material:titanium
Surface:bright
Key word:titanium rod/round bar
Type:industry,
Certification:ISO，EN10204 3.1，EN10204 3.2
Standard:ASTM B348
Shape:Flat/Square/as customer request shape cutting

Product Description

Standard	ASTM B348
Grade	GR7
Diameter	1.0-300mm
Length	1000mm-12000mm
Technique	Hot Forging & Hot Rolling
Surface	Bright
Shape	Round
Application	Industry,checmical,aerospace,medical

Mechanical Properties

Grade	Status	Tensile Strength		Yield Strength		Elongation	Area of Reducation
		Ksi	Mpa	Ksi	Mpa	%
		≥
GR1	Annealed	35	240	25	170	24	30
GR2		50	345	40	275	20	30
GR3		65	450	55	380	18	30
GR4		80	550	70	483	15	25
GR5		130	895	120	828	10	25
TI-6AL-4VELI		125	860	115	795	10	25
GR6		120	828	115	483	15	25
GR7		50	345	40	275	20	30
GR9		90	620	70	483	15	25
GR11		35	240	25	170	24	30
GR12		70	483	50	345	18	25
