Titanium wire and Fillers

Product Name:

Titanium wire and Fillers

No. :

Product Description:

Titanium Wire /Fillers

ASTM B863 titanium & titanium alloy wires

1. Product name: Titanium wire, Titanium silk

2. Grade: Gr1, Gr2, Gr3, Gr4, Gr5, Gr6, Gr7, Gr9, Gr12, Gr23
3. Standard: ASTM B348 ASTMB863 ASTM F4928 ASTM F67 ASTM F136
4. Dimentions:Dia 0.2 - 7.0mm
5. Condition: Thermal processing condition (R), Cold-work condition (Y),
Annealed (M)
6. Surface: As-rolled, pickling or polished to shinny

Titanium wire, CP Ti wire used for redrawing, welding, mesh weaving,
making optical frame, needles, electrode, etc.

Titanium is primarily alloyed with aluminum, molybdenum, iron and vanadium,
as well as other metals. These alloys are used in applications in which lightweight
strength and extreme heat resistance are required, such as in the aerospace industry,
chemical, petrochemical and general industry.

This alloy is permanent, provides good coverage and is an excellent reflector of
infrared radiation.

Feature of titanium wire

· High strength;

· Fine corrosion resistance;

· Low density, light weight;

· high/low temperature resistance;

· High resistance to strong acid.alkali.

Mechanical properties in room temperature

Grade	Tensile strength Rm/MPa(>=)	Provision of non-proportional Extension strength Rp0.2/MPa	Break Elongation aA/%(>=)	Duction of cross sectional area Z/%
Gr1	240	140	24	30
Gr2	400	275	20	30
Gr3	500	380	18	30
Gr4	580	485	15	25
Gr5	895	825	10	25
Gr6	785	680	10	25
Gr7	370	250	20	25
Gr12	485	345	18	25
Gr23	830	760	10	15
